Citrix 1Y0-204 - Citrix Virtual Apps and Desktops 7 Administration exam

 According to the Local Host Cache documentation, when the Site database is inaccessible for 90 seconds, the principal broker (Citrix Broker Service) on a Delivery Controller switches to the Local Host Cache mode and uses its local database to broker new sessions. The other Delivery Controllers in the Site do not broker any sessions during the outage. Therefore, option A is the correct answer.

 According to the Citrix documentation1, the correct syntax for adding a simple ACL rule is:

add simpleacl -srcIP [-destIP ] [-TTL ]

The correct syntax for adding an extended ACL rule is:

add ns acl -srcIP [-destIP ] [-TTL ]

Therefore, the correct answer is B, because it uses the extended ACL rule format and specifies the destination IP address of the load balancing virtual server (192.168.100.25) and the TTL value of 10 minutes (600 seconds).

1: https://docs.citrix.com/en-us/citrix-adc/13/networking/acl.html

 The Citrix Universal Print Server provides universal printing support for network printers. The Universal Print Server uses the Universal print driver, a single driver on the Multi-session OS machine that allows local or network printing from any device, including thin clients and tablets. This feature can help reduce the number of Windows drivers on the VDA machines by using a single driver for all network printers

 MAC-based forwarding (MBF) can be used to avoid multiple route/ARP lookups and to avoid asymmetrical packet flows. MBF caches the MAC address of the upstream router that forwarded the client request to the appliance. When a reply is received, it is passed through to the same router that sent the client request without going through any route lookup

 To ensure the line-of-business application is added to Favorites and users cannot remove it, the Citrix Administrator should add the phrase “KEYWORDS: Mandatory” to the application properties3.

To get application enumeration working in a Citrix Cloud migration scenario with on-premises StoreFront and Citrix ADC, the administrator needs to add the Citrix Cloud Connectors as Secure Ticket Authority (STA) servers on both Citrix ADC and StoreFront12.

 According to the Citrix documentation, the Citrix Cloud Connector is a Citrix component that serves as a channel for communication between Citrix Cloud and the resource locations, enabling cloud management without requiring any complex networking or infrastructure configuration. This removes all the hassle of managing delivery infrastructure. The Cloud Connector also provides services for the Citrix Cloud Delivery Controllers to configure the resource location where Citrix Provisioning runs. Therefore, the administrator needs to install Citrix Cloud Connectors on the Citrix Provisioning servers to migrate the Citrix Provisioning environment to Citrix Cloud1

According to the Citrix documentation1, the triggerMonitor parameter specifies the conditions under which the service monitor is invoked. The possible values are:

ALWAYS: The service monitor is always invoked.

MEPDOWN: The service monitor is invoked only when Metric Exchange Protocol (MEP) has marked the service as DOWN for any reason.

MEPSUSPECT: The service monitor is invoked only when MEP has marked the service as SUSPECT.

NONE: The service monitor is never invoked.

Therefore, the command set gslb site SiteB –triggerMonitor MEPDOWN will set the triggerMonitor value to MEPDOWN for SiteB, which means the service monitor is invoked only when MEP has marked the service as DOWN for any reason.

1: https://docs.citrix.com/en-us/citrix-adc/13/gslb/configure-gslb-site.html

The issue is caused by the policy expression of the no_chunk_pol being ‘true’ and ‘NOT HTTP.REQ.IS_VALID’. This means that the policy will always be true and thus, always be invoked, preventing the other policy from being used. This is explained in the Citrix Virtual Apps and Desktops 7 Deployment and Administration (CWS-215) course, under the section “Load Balancing Virtual Server Rewrite Policy Binding”.
