Splunk SPLK-1002 - Splunk Core Certified Power User Exam

As mentioned before, there are two types of workflow actions: GET and POST1. Both types of workflow actions can be executed from search results by clicking on an event field value that has a workflow action configured for it1. Another type of workflow action is Search, which runs another search based on the field value1. Therefore, options A, B and D are correct, while option C is incorrect because LOOKUP is not a type of workflow action.

In this case, the outer join is applied, which means that all rows from the outer (left) table will be included, even if there are no matching rows in the inner (right) table. The result will include all five rows from the outer table, with the matched data from the inner table where employeeNumber matches. Rows without matching employeeNumber values will have null values for the fields from the inner table.

When using the Field Extractor (FX) tool in Splunk and the tool fails to extract a value from all appropriate events, there are specific steps you can take to improve the extraction process. These steps involve interacting with the FX tool and possibly adjusting the extraction method:

A. Select an additional sample event with the Field Extractor (FX) and highlight the missing value in the event. This approach allows Splunk to understand the pattern better by providing more examples. By highlighting the value in another event where it wasn't extracted, you help the FX tool to learn the variability in the data format or structure, improving the accuracy of the field extraction.

D. Edit the regular expression manually. Sometimes the FX tool might not generate the most accurate regular expression for the field extraction, especially when dealing with complex log formats or subtle nuances in the data. In such cases, manually editing the regular expression can significantly improve the extraction process. This involves understanding regular expression syntax and how Splunk extracts fields, allowing for a more tailored approach to field extraction that accounts for variations in the data that the automatic process might miss.

Options B and C are not typically related to improving field extraction within the Field Extractor tool. Re-ingesting data (B) does not directly impact the extraction process, and changing to a delimited extraction method (C) is not always applicable, as it depends on the specific data format and might not resolve the issue of missing values across events.

The correct answer is C. ‘weekly_sales (3.99, 10)’. This is because search macros accept arguments without quotation marks or dollar signs, and the number of arguments must match the number of parameters defined in the macro. The other options are incorrect because they either use quotation marks or dollar signs around the arguments, or they provide a different number of arguments than the macro expects. You can learn more about how to use search macros in searches from the Splunk documentation1.

The search string below returns events from the data model named Application_State.

| datamodel Application_State All_Application_State search

The search string does the following:

It uses the datamodel command to access a data model in Splunk. The datamodel command takes two arguments: the name of the data model and the name of the dataset within the data model.

It specifies the name of the data model as Application_State. This is a predefined data model in Splunk that contains information about web applications.

It specifies the name of the dataset as All_Application_State. This is a root dataset in the data model that contains all events from all child datasets.

It uses the search command to filter and transform the events from the dataset. The search command can use any search criteria or command to modify the results.

Therefore, the search string returns events from the data model named Application_State.

The Splunk Common Information Model (CIM) provides a methodology to normalize data from different sources and source types. The CIM defines a common set of fields and tags for different types of data, such as web, network, email, etc. This allows you to search and analyze data from different sources in a consistent way.

Stacked charts represent a series in a single bar with multiple sections. A chart is a graphical representation of data that shows trends, patterns, or comparisons. A chart can have different types, such as column, bar, line, area, pie, etc. A chart can also have different modes, such as split-series, multi-series, stacked, etc. A stacked chart is a type of chart that shows multiple series in a single bar or area with different sections for each series

When using multiple expressions in a single eval command in Splunk, the delimiter used is a comma (,). This allows for the execution of multiple operations within a single eval statement, separating each operation clearly.
