Cisco 350-701 - Implementing and Operating Cisco Security Core Technologies (SCOR 350-701 v2.0)

To add a device into Cisco DNA Center with the native API, the POST method and the name attribute are required. The POST method is used to create a new resource on the server, such as a device. The name attribute is used to specify the hostname or IP address of the device to be added. The POST method requires a JSON body that contains the device information, such as the name, type, role, credentials, and other optional parameters. The Cisco DNA Center API documentation provides an example of the JSON body and the response for adding a device1. The Cisco DNA Center Platform User Guide also explains how to use the native API to add devices2. References := 1: Cisco DNA Center API Documentation - Add Device 2: Cisco DNA Center Platform User Guide, Release 2.3.5 - Manage Devices Using the Native API

Explanation

In its essence, FlexVPN is the same as DMVPN. Connections between devices are still point-to-point GRE tunnels, spoke-to-spoke connectivity is still achieved with NHRP redirect message, IOS routers even run the same NHRP code for both DMVPN and FlexVPN, which also means that both are Cisco’s proprietary technologies.

The weak element is MD5, an obsolete hash with practical collision weaknesses, so it should be replaced with a modern integrity algorithm. SHA-512 is a SHA-2 family hash and provides strong integrity validation; therefore, option C is correct. AES-256 remains a strong confidentiality algorithm, and TLS 1.3 with properly validated signed certificates provides current transport security and authentication. Replacing AES with 3DES would reduce security and introduce a legacy cipher. Replacing TLS 1.3 with DES is technically mismatched because TLS is a protocol while DES is an obsolete cipher. SSLv3 is deprecated and would also weaken the design. Cisco’s Next Generation Cryptography recommendations classify MD5 for integrity as “Avoid” and SHA-256, SHA-384, and SHA-512 as next-generation choices. Cisco’s cryptographic recommendations directly support replacing MD5 with SHA-512.

Explanation

A posture policy is a collection of posture requirements, which are associated with one or more identity groups, and operating systems. We can configure ISE to check for the Windows patch at Work Centers > Posture > Posture Elements > Conditions > File.

In this example, we are going to use the predefined file check to ensure that our Windows 10 clients have the critical security patch installed to prevent the Wanna Cry malware.

 Secret key cryptography, also known as symmetric key cryptography, is a type of encryption where a single secret key is used for both encryption and decryption of a message. The cryptographic key is kept secret between the sender and receiver, making it difficult for anyone else to decipher the message. Some of the functions of secret key cryptography are:

Key selection without integer factorization: Secret key cryptography does not rely on complex mathematical problems such as integer factorization or discrete logarithms to generate keys. Instead, the keys are chosen randomly or derived from a passphrase or a shared secret. This makes the key generation process faster and simpler than in public key cryptography.

Utilization of less memory: Secret key cryptography uses less memory than public key cryptography, as it only requires one key to be stored and managed. Public key cryptography, on the other hand, requires two keys (public and private) for each user, which increases the memory overhead and complexity of key management.

The other options are not functions of secret key cryptography, but rather characteristics of public key cryptography or asymmetric cryptography, which is a different type of encryption where different keys are used for encryption and decryption. Public key cryptography has the following features:

Utilization of different keys for encryption and decryption: Public key cryptography uses a pair of keys, one public and one private, for each user. The public key can be shared with anyone, while the private key must be kept secret. The public key is used to encrypt messages, while the private key is used to decrypt them. This allows users to communicate securely without having to exchange a secret key beforehand.

Utilization of large prime number iterations: Public key cryptography relies on hard mathematical problems such as integer factorization or discrete logarithms to generate keys. These problems involve finding the prime factors of large numbers or finding the discrete logarithms of numbers in a finite field. These problems are easy to solve in one direction, but hard to solve in the reverse direction. For example, it is easy to multiply two large prime numbers, but hard to find the prime factors of the product. This makes the keys hard to break by brute force or other methods.

Provides the capability to only know the key on one side: Public key cryptography enables users to encrypt messages without knowing the recipient’s key, and vice versa. This is possible because the encryption and decryption keys are different and mathematically related. For example, Alice can encrypt a message with Bob’s public key, and only Bob can decrypt it with his private key. Alice does not need to know Bob’s private key, and Bob does not need to know Alice’s key. This also enables public key cryptography to support digital signatures, which are a way of verifying the identity and integrity of a message.

References :=

What Is Secret Key Cryptography? A Complete Guide - Helenix

Definition of Secret-key Cryptography - Gartner

Always-On VPN enforces use of the Cisco Secure Client tunnel whenever an endpoint is outside a trusted network. The client automatically establishes the VPN after user logon, keeps the session active, and continually attempts to restore it if connectivity is interrupted. Administrators can remove the user’s ability to disconnect by disabling the Allow VPN Disconnect setting in the client profile. Smart Tunnel is a legacy application-access technique and does not enforce continuous full-client VPN connectivity. Path MTU Discovery determines a usable packet size and is unrelated to session enforcement. Allow Local LAN Access permits access to local resources while the tunnel is active, which can weaken isolation but does not keep the tunnel connected. Consequently, Always-On is the feature that meets the requirement. Cisco Secure Client Always-On VPN guide

Threat intelligence collects and contextualizes indicators associated with malicious activity so security controls and analysts can recognize adversary infrastructure and artifacts. Examples include malicious IP addresses and domains, file hashes, malware characteristics, command-and-control infrastructure, and related tactics, techniques, and procedures. Therefore, option D is the best answer. Firewall syslogs and routing tables may provide local telemetry for investigation, but they are not, by themselves, the clearest representation of gathered intelligence about known threats. Performance metrics describe network health rather than adversary behavior. Collecting users’ personal browsing data is neither the defined purpose nor an appropriate general description of threat intelligence. Cisco Talos reporting commonly supplies file hashes, domains, and IP addresses connected with malicious operations, allowing products and SOC teams to detect and block related activity. Cisco’s threat-intelligence guidance supports option D.

================

Cisco Security Intelligence is a feature that allows you to block or monitor traffic based on IP addresses or domain names that are known to be malicious or suspicious. Cisco Security Intelligence requires a Protect license on the Cisco Next Generation Intrusion Prevention System (NGIPS), which is part of the Firepower Threat Defense (FTD) software. A Protect license allows you to perform intrusion detection and prevention, file control, and Security Intelligence filtering1. The other license options (control, malware, and URL filtering) do not enable Cisco Security Intelligence on the NGIPS. References:

Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0, section “Security Intelligence”

Firepower Management Center Configuration Guide, Version 6.0, section “Licensing the Firepower System”

 Cisco AMP for Endpoints provides next-generation protection by leveraging an endpoint protection platform (EPP) and endpoint detection and response (EDR) capabilities. EPP is a set of multifaceted prevention techniques that stop threats from compromising endpoints, such as behavioral analytics, machine learning, and signature-based methods. EDR is a set of powerful features that reduce the attack surface and remediate faster, such as advanced threat hunting, endpoint isolation, and dynamic malware analysis. Cisco AMP for Endpoints also integrates with SecureX, a built-in platform that offers extended detection and response (XDR) capabilities across multiple control points, such as network, cloud, email, and web. By combining EPP, EDR, and XDR, Cisco AMP for Endpoints delivers a comprehensive and resilient endpoint security solution that can detect, respond, and recover from sophisticated attacks. References:

Cisco Secure Endpoint (Formerly AMP for Endpoints) - Cisco

Cisco Secure Endpoint (Formerly AMP for Endpoints) - Cisco

Cisco Secure Endpoint (Formerly AMP for Endpoints) - Cisco

Explanation

Explanation

The traditional use of the pull model, where the client requests data from the network does not scale when what you want is near real-time data. Moreover, in some use cases, there is the need to be notified only when some data changes, like interfaces status, protocol neighbors change etc.

Model-Driven Telemetry is a new approach for network monitoring in which data is streamed from network devices continuously using a push model and provides near real-time access to operational statistics.

Applications can subscribe to specific data items they need, by using standard-based YANG data models over NETCONF-YANG. Cisco IOS XE streaming telemetry allows to push data off of the device to an external collector at a much higher frequency, more efficiently, as well as data on-change streaming.

Stateful failover means that the connection state information is replicated from the active ASA to the standby ASA, so that in the event of a failover, the connections are preserved and do not need to be reestablished. Stateless failover means that the connection state information is not replicated, so that in the event of a failover, the connections are dropped and need to be reestablished by the end hosts. Stateful failover provides a smoother transition and less disruption to the network traffic, while stateless failover is simpler and less resource-intensive. References:

Failover for High Availability - Cisco

Failover Types / ASA Failover Addresses / Failover Requirements | Cisco …

A destination list is a list of internet destinations: domains, URLs, and CIDRs. To control identity access to specific destinations, you can add destination lists to Umbrella and then select them when configuring your Web and DNS policies12. When you add or edit a destination list, the changes are applied immediately if the destination list is part of a policy3. This means that any identities that are associated with the policy will be affected by the changes in the destination list. You do not need to save the configuration or remove the destination list from the policy to apply the changes. However, you do need to have the appropriate user role to manage destination lists. The user role of Block Page Bypass or higher is needed to perform these changes4. References :=

Manage Destination Lists - Umbrella User Guide

Manage Destination Lists - Umbrella SIG User Guide

Add a Destination List - Umbrella User Guide

Add a DNS Destination List - Umbrella SIG User Guide

Explanation

Explanation

Cisco Firepower NGFW Virtual (NGFWv) is the virtualized version of Cisco’s Firepower next generation firewall.

The Cisco NGFW virtual appliance is available in the AWS and Azure marketplaces. In AWS, it can be

deployed in routed and passive modes. Passive mode design requires ERSPAN, the Encapsulated Remote Switched Port Analyzer, which is currently not available in Azure.

In passive mode, NGFWv inspects packets like an Intrusion Detection System (IDS) appliance, but no action can be taken on the packet.

In routed mode NGFWv acts as a next hop for workloads. It can inspect packets and also take action on the packet based on rule and policy definitions.
