Huawei H12-821_V1.0 - HCIP-Datacom-Core Technology V1.0

ï‚· ACL in Routing Policies

ACLs are frequently used in routing policies to match specific routes based on criteria such as source IP, destination IP, and more. This allows ACLs to influence route redistribution, filtering, and forwarding decisions.

ï‚· HCIP-Datacom-Core Reference

ACL applications in routing policies are discussed in the routing policy chapters​​.

Comprehensive and Detailed Step-by-Step Explanation:

Understanding the ACL Configuration:

ACL Number: 3001 is an advanced ACL.

Rule Description: The rule permits ICMP packets with the following criteria:

Source IP: 192.168.1.3 (host-specific).

Destination IP: 192.168.2.0/24 (entire subnet).

Analysis of Each Option:

Option A: True. ICMP packets from 192.168.1.3 to 192.168.2.200 (within the subnet) are permitted.

Option B: True. Packets from 192.168.1.2 (not matching the source) are denied by default.

Option C: False. The ACL only permits ICMP packets, not general IP packets.

Option D: True. The ACL is identified by the number 3001.

Comprehensive and Detailed Step-by-Step Explanation:

BGP Origin Attribute Priority:

The Origin attribute determines the source of the route and affects the selection of the best path.

The priority order is as follows:

IGP (i): Highest priority. Routes injected using the network command.

EGP (e): Lower priority. Routes learned from the EGP protocol.

Incomplete (?): Lowest priority. Routes redistributed into BGP from other protocols.

Correct Option:

A: IGP > EGP > Incomplete is the correct order of priority.

IGMP Version Mismatch

If the IGMP snooping version on the device is earlier than the IGMP version on user hosts, the device may fail to parse IGMP Report messages correctly. As a result, the device forwards these messages only to router ports without generating group member ports or forwarding entries.

Consequently, users cannot receive multicast data.

HCIP-Datacom-Core Reference

Multicast and IGMP snooping behaviors under mismatched conditions are described in the multicast configuration chapters​​.

Comprehensive and Detailed in-depth Step-by-Step Explanation:

BGP confederations are used to reduce the complexity of IBGP full-mesh connections within a large AS by dividing the AS into multiple sub-ASs (called " member ASs " ) while still appearing as a single AS to external ASs. Below is an analysis of each option:

A. The ASs outside a confederation still consider the confederation as one AS:

This is true. Externally, the entire confederation is seen as a single AS, identified by the main AS number.

B. After a confederation is configured, the original IBGP attributes can be retained:

This is true. The configuration of a confederation does not affect the IBGP attributes exchanged between routers.

C. After a confederation is configured, the original AS number is used as the confederation ID of each router:

This is true. The main AS number is used as the Confederation Identifier for all member ASs in the confederation.

D. A confederation divides an AS into several sub-ASs, and EBGP full-mesh connections are established in each sub-AS:

This is false. Within each sub-AS of a confederation, IBGP connections are still used (not EBGP). Confederations are designed to reduce the number of IBGP full-mesh connections required within a large AS by creating smaller, manageable sub-ASs.

Therefore, the correct answer is D.

ï‚· Edge Port Behavior

An edge port transitions directly to the Forwarding state but reverts to participating in RSTP calculations if it receives a valid configuration BPDU. Thus, statement C is false.

ï‚· HCIP-Datacom-Core Reference

The behavior of edge ports and their transitions are discussed in the RSTP enhancement sections​​.

The scenario describes a mismatch in OSPF network types between two connected routers: one set to Point-to-Point (P2P) and the other set to Point-to-Multipoint (P2MP). While aligning Hello intervals may seem sufficient for establishing an OSPF neighbor relationship, the fundamental mismatch in network types introduces issues.

OSPF Network Types

P2P : Assumes a direct connection with a single neighbor, uses faster convergence and simpler LSDB synchronization.

P2MP : Supports multiple neighbors on a single interface, requiring different handling for DR/BDR roles and LSDB updates.

Impact of Network Type Mismatch

If Hello intervals are aligned, adjacency establishment might occur. However, mismatched network types affect neighbor role assignment and LSDB synchronization.

P2P expects a direct link and would handle updates differently than P2MP, which assumes multiple neighbors. This leads to inconsistencies in route calculation and forwarding.

HCIP-Datacom-Core Reference

OSPF Basics and Configuration ​clearly outlines the criticality of consistent network type configuration for stable OSPF operation.

Lab examples in the HCIP Datacom Lab Guide​further demonstrate the consequences of such mismatches, including unstable neighbor states and incomplete LSDB synchronization.

Hence, the statement that neighbor relationships and LSDB synchronization remain unaffected is incorrect. Proper OSPF operation requires matching network types in addition to aligned Hello intervals.

A is correct – Removing unused accounts helps minimize the risk surface .

B is false – Email is not a secure method for transferring sensitive information like passwords, even if encrypted.

C is correct – Unique administrator accounts help with accountability and tracking.

D is false – Long-term password validity reduces security. Passwords should be rotated regularly.

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“To secure admin access, avoid account sharing, delete inactive users, and periodically update credentials through secure channels.”

(Chapter: Device Security – Section: Account Management)

Network Types and Corresponding Link Layer Protocols

Broadcast : Ethernet

Point-to-Point (P2P) : PPP, HDLC

Point-to-Multipoint (P2MP) : PPP

Non-Broadcast Multi-Access (NBMA) : Frame Relay

ï‚· OSPF Network Types:

OSPF classifies networks based on link layer protocols into the following types:

Broadcast: This type assumes that all routers on the network can communicate directly with one another using multicast or broadcast frames. Ethernet networks are typical examples.

Point-to-Point (P2P): This type is used for links that connect two routers directly. Common protocols include PPP (Point-to-Point Protocol) and HDLC.

Point-to-Multipoint (P2MP): This type simulates multiple point-to-point connections over a single physical network, often used in WAN scenarios where PPP is employed.

Non-Broadcast Multi-Access (NBMA): These networks connect multiple devices but lack native broadcast capability, such as Frame Relay.
