International Code Council M2 - Commercial Mechanical Inspector

For cooking equipment with exposed flame and burners , the IMC table for grease-filter mounting position requires a minimum vertical separation of 24 inches between the lowest edge of the grease filter and the cooking surface. That makes B correct.

For commercial kitchen exhaust associated with Type I hood systems, the recognized code-based minimum duct transport velocity is 1,500 feet per minute , so C is the correct answer. Option B uses the wrong unit, and the other listed velocities do not match the code minimum used for this question type.

Based on the mechanical plan shown in the exhibit, the gas line between unit heaters 5 and 8 is labeled as 1 inch in diameter. Therefore, the correct answer is B.

The IMC appliance provisions prohibit duct connection to a vented wall furnace . That makes Option B correct. The exam tests recognition of appliance-specific distribution restrictions rather than general duct rules.

For a single-wall vent connector serving one appliance, the maximum horizontal length is determined from the vent connector sizing and length rules. For a 5-inch diameter connector with a 10-foot vent height , the permitted maximum horizontal length is 7.5 feet . Therefore, Option B is correct.

The applicable provision requires direct-fired industrial air heaters to supply outside ventilation air at a rate of not less than 4 cfm per 1,000 Btu/h of rated input where ventilation air is provided by separate mechanical means. For 200,000 Btu/h , the required outside air is:

200,000 ÷ 1,000 = 200

200 × 4 = 800 cfm

So the correct answer is C

Based on the equipment schedule shown in the exhibit, EF-2 is listed with a motor size of 1.5 horsepower . Therefore, the correct answer is C .

The IMC states that solar thermal equipment exposed to vehicular traffic must be installed not less than 6 feet above the finished floor . It then gives an exception stating that this requirement does not apply where the equipment is protected from motor vehicle impact . Because the height requirement is removed by that exception, the best answer from the choices given is A, directly on finished floor . This is an inference from the exception language.

For this type of continuously ventilated exhaust shaft serving a multifamily building, the code requires the kitchen exhaust connection to penetrate the shaft and extend vertically not less than 22 inches without a fire damper. That matches Option D .
