Paloalto Networks PCNSE - Palo Alto Networks Certified Security Engineer (PCNSE) PAN-OS 11.0

A and D are the best practice deployment modes for the firewall if the company wants to add threat prevention to the network without redesigning the network routing. This is because these modes allow the firewall to act as a transparent device that does not affect the existing network topology or routing1.

A: VirtualWire mode allows the firewall to be inserted into any existing network segment without changing the IP addressing or routing of that segment2. The firewall inspects traffic between two interfaces that are configured as a pair, called a virtual wire. The firewall applies security policies to the traffic and forwards it to the same interface from which it was received2.

D: Layer 2 mode allows the firewall to act as a switch that forwards traffic based on MAC addresses3. The firewall inspects traffic between interfaces that are configured as Layer 2 interfaces and belong to the same VLAN. The firewall applies security policies to the traffic and forwards it to the appropriate interface based on the MAC address table3.

Verified References:

1: https://www.garlandtechnology.com/blog/whats-your-palo-alto-ngfw-deployment-plan

2: https://docs.paloaltonetworks.com/pan-os/10-1/pan-os-admin/networking/configure-interfaces/virtual-wire.html

3: https://docs.paloaltonetworks.com/pan-os/10-1/pan-os-admin/networking/configure-interfaces/layer-2.html

When using the log forwarding built-in action with tagging in Palo Alto Networks firewalls, the primary purpose is to dynamically respond to threats or unwanted traffic identified by the firewall's threat detection mechanisms. The action involves tagging the IP address associated with the unwanted traffic and then using that tag in dynamic security policies to block or manage the traffic.

A. Destination IP addresses of selected unwanted traffic are blocked:

When the tagging action is used, the firewall tags the IP addresses involved in the unwanted traffic (which could be the source or destination IP addresses, but in many configurations, the focus is on the source of the attack). These tags can then be referenced in Dynamic Address Groups (DAGs) within security policies. Consequently, any traffic coming from or going to these tagged IP addresses can be blocked or subjected to specific security rules, effectively mitigating the threat or unwanted behavior.

This approach allows for automated, real-time responses to identified threats, enhancing the security posture by quickly adapting to emerging threats without manual intervention.

>Threat logs, create a log forwarding profile to define how you want the firewall or Panorama to handle logs. >Configure an HTTP server profile to forward logs to a remote User-ID agent. > Select the log forwarding profile you created then select this server profile as the HTTP server profile https://docs.paloaltonetworks.com/pan-os/11-0/pan-os-admin/policy/use-auto-tagging-to-automate-security-actions

When implementing an application override in a Palo Alto Networks firewall, the primary goal is to explicitly define how specific traffic is identified and processed by the firewall, bypassing the regular App-ID process. This is particularly useful for traffic that might be misidentified by App-ID or for applications that require special handling for performance reasons.

To successfully implement application override, the following items must be configured:

B. Application override policy rule:

This is a specialized policy rule that you create to specify the criteria for the traffic you want to override. In this rule, you define the source and destination zones, addresses, and ports. Instead of relying on the App-ID engine to identify the application, the firewall uses the criteria defined in the application override policy to classify the traffic.

C. Security policy rule:

After defining an application override policy, you must also configure a security policy rule to allow the overridden traffic through the firewall. This rule specifies the action (allow, deny, drop, etc.) for the traffic that matches the application override policy. It's essential to ensure that the security policy rule matches the traffic defined in the application override policy to ensure that the intended traffic is allowed through the firewall.

For detailed guidance on configuring application override and the necessary security policies, refer to the official Palo Alto Networks documentation. This resource provides step-by-step instructions and best practices for effectively managing traffic using application overrides.
