CompTIA 220-1101 - CompTIA A+ Certification Exam: Core 1

The clicking sound is the sound of a damaged disk in the HDD

A clicking sound from a hard disk drive typically indicates a mechanical failure, such as the read/write head hitting a physical obstruction or a problem with the disk motor. This can cause the drive to fail to initialize or not be recognized by the system during booting.

The most likely cause of the issue is that the page orientation is incorrect. The printer may be set to print labels in a different orientation than the orientation of the label sheet1.

Installing an M.2 SSD will improve a workstation's overall response time for frequently used applications and data without removing the current hard drive. M.2 drives are faster and more efficient than traditional hard drives, making them a good option for increasing overall performance. References: CompTIA A+ Certification Exam Core 1 Exam Objectives - 1.5 Given a scenario, configure storage devices and use appropriate media

he main difference between T568A and T568B cabling standards is that the green and orange cables are interchanged12. T568A is designed for backward compatibility with older telephone wires, while T568B is designed for better signal isolation and noise protection for newer networking systems and products3. T568A is used in blue cables, and T568B is used in green cables1. The standards use the same cable connectors3.

solution as

RAID 10 array is often used for server virtualization as it provides both redundancy and performance benefits. It uses a combination of mirroring and striping to provide both fault tolerance and improved I/O performance. An optical disk drive or eMMC storage device would not provide enough storage or performance for a VM host server, while a 15,000rpm drive may provide good performance but would not provide redundancy for fault tolerance. Therefore, a RAID 10 array is the best option for cost-effective storage that will be used for all VMs that run from the server.

PaaS (Platform as a Service) is a cloud computing model in which a provider offers a platform that allows developers to create, run, and manage applications without the complexity of building and maintaining the infrastructure. An application development environment is a valid use for PaaS. References: CompTIA A+ Certification Exam Objectives 1001, 1.7

DMARC (Domain-based Message Authentication, Reporting and Conformance) is an email authentication protocol. It is designed to give email domain owners the ability to protect their domain from unauthorized use, commonly known as email spoofing.

Dot Matrix printers do not use heat, they use a pin striking an inked ribbon (for the first copy, the subsequent copies are handled by the carbon paper)

The ribbon is low on ink or missing and must be replaced to get proper output in a dot matrix printer that uses carbon paper. References: CompTIA A+ Certification Exam Guide, Exam 220-1001, Page 361

The 802.11n wireless networking standard supports Multiple Input Multiple Output (MIMO) technology. MIMO technology uses multiple antennas on both the transmitting and receiving devices to improve wireless performance by increasing the amount of data that can be transmitted simultaneously. 802.11a, 802.11b, and 802.11g do not support MIMO technology. References: CompTIA A+ Certification Exam: Core 1 - Objective 3.3

A defective battery is the most likely cause of a mobile phone that gets really hot to the touch, does not retain a charge, and is slow while charging. A defective battery can cause the phone to overheat and may also cause performance issues. References: CompTIA A+ Certification Exam Objectives 1001, 2.14

FTP (File Transfer Protocol) uses TCP ports 20/21 and transfers data in cleartext, which means the data is not encrypted and can be read by anyone who intercepts it. This makes FTP insecure for transferring sensitive information. SSH (Secure Shell), on the other hand, uses port 22 and encrypts data, making it more secure. SNMP (Simple Network Management Protocol) uses ports 161/162 and is used to monitor network devices. Telnet uses port 23 and transfers data in cleartext, making it insecure. References: CompTIA A+ Certification Exam: Core 1 - Page 199

In this situation, the best course of action for the technician to take NEXT would be C. Verify the socket type and manufacturer. If the pins on the CPU do not line up with the socket on the motherboard, it is likely that there is a compatibility issue between the two components. The technician should verify that the socket type and manufacturer of the motherboard match those of the CPU to ensure that they are compatible.

The flashing green and orange LEDs on the NIC indicate connection issues. The technician should first check for loose connections, pinched bends, and physical damage, which are the most common causes of connection problems. References: CompTIA A+ Certification Exam Guide, Ninth Edition, Chapter 14

The symptoms—flashing green and orange LEDs on the workstation’s NIC—suggest a connectivity issue. In networking troubleshooting, flashing LEDs typically indicate activity (green for link/activity, orange for speed or errors, depending on the NIC), but the combination and context imply an unstable or degraded connection. The cable length of 275ft (84m) is within the maximum distance for Cat 5 UTP (100 meters or 328 feet), so length alone isn’t the immediate problem. However, physical issues like loose connections, pinched bends, or damage could degrade signal quality, causing intermittent or erroneous data transmission.

The CompTIA A+ Core 1 Study Guide emphasizes a systematic troubleshooting approach, starting with the simplest and most common causes before escalating to more complex solutions. Checking the cable’s physical integrity—ensuring proper termination, no sharp bends, and no cuts or interference—is a fundamental first step in network troubleshooting. This aligns with Objective 5.5 ("Given a scenario, troubleshoot problems related to motherboards, RAM, CPU, and power") and Objective 5.2 ("Given a scenario, troubleshoot and diagnose problems with storage drives and RAID arrays"), which extend to networking in practice.

Option A (Check for loose connections, pinched bends, and physical damage): This is the least invasive, most immediate step to rule out common cabling issues, as recommended by CompTIA’s methodology.

Option B (Install a powered hub halfway): Adding a hub or repeater could extend signal strength, but the length is within spec, and this assumes a distance issue without evidence. It’s not the first step.

Option C (Replace with Cat 5 STP): Shielded twisted pair reduces interference, but there’s no indication of EMI yet, and replacing the cable is premature without basic checks.

Option D (Upgrade to multimode fiber): Fiber eliminates distance and interference issues but is a costly, last-resort solution, not a first step.

The study guide prioritizes physical inspection and basic diagnostics before hardware replacements or upgrades, making Option A the correct initial action.

Exact Extracts from the Study Guide:

From The Official CompTIA A+ Core 1 Study Guide (220-1101):

Section 2.6, Networking Hardware:

"Twisted Pair Cabling: The maximum length of a twisted pair cable run (such as Cat 5, Cat 5e, or Cat 6) is 100 meters (328 feet). This includes both patch cables and the main run. Beyond this length, signal degradation (attenuation) becomes significant, and a repeater or switch is needed to boost the signal."

Implication: At 275ft (84m), the cable is within spec, so length isn’t the primary concern.

Section 5.4, Troubleshooting Wired and Wireless Network Problems:

"No connectivity or intermittent connectivity—Check the following: Ensure that all cables are securely connected at both ends (NIC and switch or wall jack). Inspect the cable for damage, such as cuts, crimps, or excessive bending, which can disrupt signal integrity… Verify that the cable length does not exceed the maximum specification for the cable type (e.g., 100 meters for twisted pair)."

"LED indicators—Most NICs and switches have LED indicators to show link status and activity. A solid green light typically indicates a good connection, while flashing may indicate activity. Amber or orange lights can indicate speed (e.g., 10/100 Mbps vs. 1 Gbps) or errors, depending on the device."

Section 5.4, Troubleshooting Methodology:

"Identify the problem… Gather information… Establish a theory of probable cause… Test the theory to determine cause (e.g., check physical connections before replacing components)."

These excerpts highlight that checking physical connections and cable condition is the first step when LEDs indicate potential issues, especially before assuming hardware failure or specification limits are exceeded.

Additional Reasoning:

LED Behavior: Flashing green and orange LEDs vary by NIC manufacturer, but per the study guide, green flashing often means activity, and orange flashing could signal errors or a speed mismatch. This suggests a link is established but unstable, pointing to cabling issues.

Cable Length: At 275ft, the run is well under 328ft, ruling out immediate need for a hub or fiber upgrade.

Common Issues: Loose RJ45 connectors, pinched cables (exceeding bend radius), or physical damage are frequent causes of intermittent connectivity, easily checked first.

Alternatives: Installing a hub (B) or replacing the cable (C, D) assumes a specific failure without evidence, violating CompTIA’s step-by-step approach.

Electromagnetic interference (EMI) is unwanted noise or interference in an electrical path or circuit caused by an outside source. Hence shielded Cat 6 is better

If a technician determines that the root cause of sporadic network connectivity issues is EMI, the most cost-effective cable medium that can be used without sacrificing system performance is shielded Cat 6 cable. Shielded cables protect against electromagnetic interference (EMI) and radio frequency interference (RFI). References: CompTIA A+ Certification All-in-One Exam Guide, Tenth Edition by Mike Meyers (Page 548)

SMTP (Simple Mail Transfer Protocol) uses port 25 to send email messages between servers12.

SMTP uses port 25 to send email messages between mail servers. Therefore, the system administrator should enable port 25 to allow SMTP traffic through the host-based firewall. References: CompTIA A+ Certification Study Guide, Tenth Edition, pg. 282

https://techlibrary.hpe.com/docs/iss/proliant-gen10-uefi/s_enabling_VT-d.html

Enabling VT-d (Virtualization Technology for Directed I/O) in the server's BIOS settings is required for the hypervisor to run properly. References: CompTIA A+ Certification Exam Guide, Ninth Edition, Chapter 11
