CompTIA 220-1101 - CompTIA A+ Certification Exam: Core 1

The technician is unable to access the company portal website, but other websites work fine. This suggests an issue with resolving the specific URL of the company portal, which is a function of DNS.

Here's why other options are not the most likely cause:

DHCP reservations: This is not relevant as the issue persists even when the technician tries a different workstation, indicating a problem beyond individual device configuration.

Static IP addresses: Similar to DHCP reservations, static IPs are not likely the cause as both affected workstations are experiencing the issue.

Default gateway: While the default gateway is necessary for internet access, other websites are working, making it less likely to be the root cause.

802.11 ax is a wireless networking protocol that supports both 2.4GHz and 5GHz devices, as well as backward compatibility with previous 802.11 standards. 802.11 ax offers higher data rates, lower latency, increased capacity, and improved power efficiency than previous protocols. It is also known as Wi-Fi 6 or High Efficiency Wireless (HEW). Reference: https://www.comptia.org/training/books/a-core-1-220-1101-study-guide (page 82)

The internal antennas are the components that allow the laptop to receive and transmit wireless signals. If the internal antennas are not connected properly, the laptop may have a weak or no Wi-Fi signal. The technician should verify that the internal antennas are connected to the wireless card and routed correctly inside the laptop case. The internal antennas may have been disconnected or damaged during the screen replacement. The device having the latest OS updates, the wireless device drivers being the latest version, airplane mode being disabled, and the battery being charging are not related to the issue, as they do not affect the physical connection of the internal antennas. References: https://www.comptia.org/blog/what-is-a-laptop-antenna

The correct answer is A. Toner probe.

A toner probe is an electronic test instrument that can help trace wires and locate the port where a printer is connected on a patch panel. A toner probe consists of two parts: a tone generator and a tone detector. The tone generator sends a signal through the cable, and the tone detector picks up the signal at the other end. By using a toner probe, a technician can identify which port on the patch panel corresponds to the printer cable.

A loopback plug is a device that can test the functionality of a network port by sending and receiving signals from the same port. A loopback plug is not useful for locating ports on a patch panel.

A cable tester is a device that can verify the integrity and continuity of a cable by checking for open, short, or miswired connections. A cable tester can also measure the length and resistance of a cable. A cable tester is not useful for locating ports on a patch panel.

A Wi-Fi analyzer is a software or hardware tool that can monitor and analyze wireless networks by scanning for available channels, signal strength, security settings, and other parameters. A Wi-Fi analyzer is not useful for locating ports on a patch panel.

ECC (Error-Correcting Code) RAM is commonly used in servers to provide error detection and correction, improving reliability in critical systems. It is designed to detect and correct single-bit errors, ensuring data integrity in environments where stability is paramount.

Option A (SODIMM): Incorrect. SODIMM is typically used in laptops, not servers.

Option B (Rambus): Incorrect. Rambus is an outdated RAM type and not commonly used today.

Option C (DDR3): Incorrect. While DDR3 is a type of RAM, it is not specific to servers and does not provide error correction.

Comprehensive and Detailed In-Depth Explanation:

Infrastructure as a Service (IaaS) provides virtualized computing resources over the internet such as servers, storage, and networking. It allows a business to quickly spin up virtual machines and is ideal for disaster recovery and scalable IT infrastructure needs.

Option B: SecaaS focuses on cloud-delivered security, not infrastructure.

Option C: PaaS offers development environments, not full virtual infrastructure.

Option D: SaaS delivers applications over the internet (e.g., email, CRM) — not for disaster recovery.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 4.1: Compare and contrast cloud computing concepts.

===========

Step by Step Detailed Comprehensive Explanation with All CompTIA References:

Analysis of the Problem:

IPv4 records are associated with "A" records in DNS servers.

Option Evaluation:

A. AAAA: Used for IPv6. Incorrect.

B. MX: Relates to email servers. Incorrect.

C. CNAME: Provides aliases, not IP mappings. Incorrect.

D. A: Maps hostnames to IPv4 addresses. Correct.

Reasoning: Many docking stations provide power and functionality only when the laptop is properly powered on. If the laptop was powered off (e.g., during the vacation), docking it will not automatically turn it on. The technician should first ensure the laptop is powered on by pressing the power button.

This is a common troubleshooting step when laptops in docking stations appear non-functional.

Relevance to CompTIA A+ Core 1: This falls under Objective 5.2, which covers diagnosing and resolving common laptop and mobile device issues.

Why the Other Options Are Incorrect:

A. Ensure the docking station is plugged in:

While ensuring power to the docking station is important, the scenario specifies that the issue occurred after a vacation. The likelihood of the docking station losing power coincidentally during the vacation is low. Verifying the laptop's power state should be the first step.

C. Plug the laptop in and let it charge overnight:

There is no indication the laptop’s battery is drained. While charging could resolve a dead battery, the user is more likely experiencing an issue where the laptop is powered off but docked, so charging overnight is not the best first step.

D. Connect the laptop directly to the network:

A network connection will not resolve the primary issue of the keyboard and display not working. Addressing the laptop’s power state is a higher priority.

Practical Example:

If a user returns from a vacation and places a powered-off laptop into a docking station, it may not automatically power on. Pressing the power button ensures the laptop is operational and communicating with the docking station.

CompTIA A+ Exam Objective Alignment:

Objective 5.2: Troubleshooting common laptop issues, including power, display, and peripheral connectivity.

VGA (Video Graphics Array) cables transmit analog video signals only and do not carry audio signals. When a user connects a laptop to an audiovisual system using a VGA cable, the lack of audio is due to VGA's inability to transmit sound. Switching to an HDMI (High-Definition Multimedia Interface) cable, which supports both audio and video signals, will most likely resolve the issue by enabling the transmission of sound to the audiovisual system alongside the video.

Comprehensive and Detailed In-Depth Explanation:

SMB (Server Message Block) is a protocol used to access files and printers over a network, including across shared network folders. It enables the user to access and print files stored remotely on a shared directory.

Option A (ADF): Automatic Document Feeder — hardware, not a network protocol.

Option B (USB): Used for direct physical connections, not for printing over networks.

Option C (PCL): Printer Command Language — relates to printer drivers, not file sharing or access.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 3.4: Given a scenario, install and configure printers.

A hybrid cloud is a cloud computing environment that combines on-premises, private cloud, and public cloud resources. This configuration allows organizations to deploy workloads and data in a way that optimizes performance, security, and cost management.

Key Characteristics of a Hybrid Cloud:

Combines private cloud (on-premises or dedicated servers) and public cloud (resources accessed over the internet).

Allows for the movement of data and applications between private and public clouds.

Supports scenarios where certain data must remain on-premises for security or compliance reasons, while other workloads utilize the scalability of public cloud resources.

Comparison to Other Options:

A. Private Cloud: A private cloud is a dedicated environment for a single organization, either on-premises or hosted by a service provider. It does not include any public cloud integration, as seen in a hybrid model.

C. Community Cloud: This model is shared among several organizations with similar requirements, typically for collaborative projects, and does not blend public and private infrastructure.

D. Public Cloud: Resources are entirely hosted on a cloud provider’s infrastructure and are shared among multiple customers, lacking the private, dedicated resources of a hybrid setup.

CompTIA A+ Exam Objectives References:

220-1101 (Core 1), Section 4.1 outlines various cloud-computing models, including private, public, hybrid, and community clouds.

Hybrid cloud is explicitly described as an environment that mixes private and public resources to deliver flexible and scalable solutions​.

Single-mode fiber uses a beam of light to transmit data over long distances through a very thin, flexible cable. It is commonly used for high-speed data transmission across wide areas, such as between buildings or over long distances within a network. Single-mode fiber offers a higher bandwidth and longer distance capabilities compared to other types of fiber optics.

D. Single-mode fiber: Transmits data using light through a fiber optic cable, making it ideal for long-distance communication.

Why the other options are incorrect:

A. Coaxial: Coaxial cables use electrical signals, not light, to transmit data.

B. HDMI: HDMI (High-Definition Multimedia Interface) is used for transmitting audio and video signals but does not use light for data transmission.

C. Thunderbolt: Thunderbolt cables transmit data using electrical signals and are typically used for high-speed data transfer and display connections.

This falls under the Networking and Hardware domain in the CompTIA A+ Core 1 exam​.

Infrastructure as a Service (IaaS) provides virtualized computing resources over the internet, including virtualized hardware, storage, and networking components. It offers the infrastructure on which clients can install their operating systems and applications, providing an equivalent to physical hardware environments. This allows developers and businesses to develop and run their solutions without managing physical servers. SaaS delivers software applications over the internet, PaaS provides a platform allowing customers to develop, run, and manage applications, and DBaaS offers database services in the cloud.

Using a USB 3.1 flash drive with BitLocker to Go installed is the best option for complying with corporate policy for data protection when copying files to portable media. References: CompTIA A+ Certification Exam Guide, Ninth Edition, Chapter 12

In this situation, the MOST cost-effective cable medium that would not sacrifice system performance would be B. Shielded Cat 6. Electromagnetic interference (EMI) can disrupt network connectivity by interfering with the signals transmitted over network cables. Shielded Cat 6 cables are designed to provide protection against EMI by incorporating a layer of shielding material around the cable’s conductors. This shielding helps to prevent EMI from interfering with the signals transmitted over the cable.

The tool that the technician should use to see all drives is Diskmgmt. Diskmgmt is a Windows utility that allows you to manage disk drives and partitions on your computer. It can be used to view all drives, including USB drives, that are connected to the computer12.

ADF/flatbed scanner would most likely be used to obtain electronic images of a large number of printed documents. References: CompTIA A+ Certification Exam Guide, Exam 220-1001, Page 351

To fix a Cat 5 cable issue where the cable fails when it is moved around, the technician would need to use an RJ45 connector (option E) and a crimper (option F). The technician can use the crimper to attach a new RJ45 connector to the end of the cable, which should resolve the issue.

An RJ45 connector (option E) is a type of connector commonly used for Ethernet networking. It is an 8-position, 8-contact (8P8C) modular plug and jack that is used to terminate Cat 5 and other types of twisted pair cables. A crimper (option F) is a tool used to attach connectors to the ends of cables. In this case, the technician would use the crimper to attach a new RJ45 connector to the end of the Cat 5 cable.

When a cable fails when it is moved around, it often indicates that there is a problem with the connector at the end of the cable. By attaching a new RJ45 connector using a crimper, the technician can ensure that the cable has a secure and reliable connection.

Changing the connector setting on the monitor is a possible solution for a PC and its monitor that display the error message "No input signal detected". This error can be caused by an incorrect input selected on the monitor, so changing the connector setting to the correct input should resolve the issue. References: CompTIA A+ Certification Exam Objectives 1001, 1.10
