VMware 3V0-24.25 - Advanced VMware Cloud Foundation 9.0 vSphere Kubernetes Service

VCF 9.0 explains pod fundamentals by describing how Workload Management introducesvSphere Pods, stating a vSphere Pod is “equivalent of a Kubernetes pod” and that it “runs one or more Linux containers.” This directly eliminates optionB, because a pod can includeone or morecontainers (not only one).

The vSphere 9.0 documentation further defines a KubernetesPodas “a group of one or more containerized applications that share such resources as storage and network,” and notes the containers inside a pod are “started, stopped, and replicated as a group.” That definition reflects Kubernetes’ scheduling and lifecycle model: Kubernetes treats the pod as the primary unit it places and manages together, which is why a pod is regarded as thesmallest deployable unitfor running containerized workloads in Kubernetes. OptionsCandDare incorrect because pods are Kubernetes objects (not “managed by Docker” as a smallest entity), and Kubernetes abstracts the underlying runtime/host so pods are not defined as being “deployed directly on the virtual machine” as a characteristic.

Log in to the Supervisor as an administrator.

Run kubectl to look up the updatejob_name.

Run kubectl proxy so that curl can be used to issue requests.

Use curl to issue a patch command to clear the .status.conditions on the Job controller.

In VMware Cloud Foundation (VCF) 9.0, managing Tanzu Kubernetes Clusters (TKC) through the vSphere Kubernetes Service (VKS) involves a declarative lifecycle managed by the vSphere Supervisor. When a TKC upgrade enters an upgradefailed state, it is typically because the underlying cluster reconciliation logic has hit a terminal error or a timeout within the Cluster API (CAPI) controllers. To resolve this, an administrator must interact directly with the Supervisor’s API server to reset the state of the upgrade job.

The troubleshooting workflow begins with authenticating to the Supervisor cluster using the kubectl vsphere login command (Step B). Once authenticated and the context is set to the correct namespace, the administrator must identify the specific job responsible for the upgrade failure by querying the namespace for job resources (Step D). Because the Supervisor API requires specific authentication tokens that are complex to manage via standard CLI tools for manual JSON patching, running kubectl proxy (Step A) is the standard procedure to create a local gateway. This allows the administrator to use a simple curl command (Step C) to send a JSON Merge Patch to the API server. The critical step is clearing the .status.conditions field. By removing the " Failed " condition, the Supervisor ' s controller-manager is triggered to re-evaluate the desired state and attempt the upgrade process again. This sequence ensures the declarative engine can resume operations without requiring a full cluster redeployment.

Istio is available in VCF 9.0 as an optional package that can be installed for VKS clusters. The VCF 9.0 documentation explicitly lists “Istio” among the optional packages that “can be optionally installed” for the vSphere Kubernetes Service (VKS). In Kubernetes platforms, Istio is a service mesh that secures and manages service-to-service (east-west) traffic by establishing authenticated and encrypted connections between workloads. The encryption mechanism it provides for inter-service communication ismutual TLS (mTLS), which means both ends (client and server workloads) authenticate each other and negotiate encrypted transport for every service call—meeting the requirement to “encrypt the transport and communications between services.” This is distinct from host-level mechanisms like IPsec/IKEv2 (network-layer) or “AES-256” (an algorithm, not the service-to-service transport model). Enabling Istio Service Mesh is therefore aligned to deliver encrypted, identity-aware service communications across the cluster at the application service layer.

VCF 9.0 distinguishes betweenbacking up the Supervisor control planeandbacking up workloadsthat run on the Supervisor, includingvSphere Pods. In the “Considerations for Backing Up and Restoring Workload Management” table, the scenario “Backup and restore vSphere Pods” explicitly lists the required tool as“Velero Plugin for vSphere”, with the guidance to “Install and configure the plug-in on the Supervisor.”

The same document is explicit thatstandalone Velero with Restic is not valid for vSphere Pods, stating: “You cannot use Velero standalone with Restic to backup and restore vSphere Pods. You must use the Velero Plugin for vSphere installed on the Supervisor.”

vCenter file-based backup is documented for restoring theSupervisor control plane state, not for backing up and restoring vSphere Pod workloads themselves. Therefore, to meet the requirement to protect third-party applications running asvSphere Pods, the architect should propose theVelero Plugin for vSphere.

A service mesh is an application communication layer that standardizesservice-to-service trafficinside Kubernetes. Instead of each development team building custom logic for retries, timeouts, encryption, and telemetry, the mesh provides these capabilities consistently across workloads. This is typically done by inserting a data plane (often sidecar proxies or node-level proxies) that intercepts inbound and outbound traffic for each microservice, plus a control plane that distributes configuration and identity material.

The key outcomes align directly to optionB: communication becomespossible(reliable connectivity patterns),structured(consistent routing rules, policies, and identity), andobservable(metrics, logs, and distributed tracing for east-west traffic). A service mesh commonly adds controls such asmTLS encryption, fine-grainedtraffic policy(allow/deny, rate limits, circuit breaking), and progressive delivery patterns (canary/blue-green) without changing application code.

By contrast, service discovery (A) is usually a built-in Kubernetes function, load balancing/autoscaling across sites (C) is not the primary definition of a service mesh, and a single centralized global routing table (D) is not how meshes are typically described or implemented.

The vSphere Kubernetes Service (VKS) in VMware Cloud Foundation (VCF) 9.0 is designed as an " enterprise-ready " Kubernetes distribution that is deeply integrated with the SDDC stack. It provides several core capabilities out-of-the-box that would otherwise require manual configuration in a generic Kubernetes installation. The four primary capabilities identified are Authentication , storage integration , pod networking , and load balancing .

First, Authentication is handled via integration with the vSphere Supervisor, which acts as an identity proxy (using Pinniped and OIDC) to allow users to log in using their vSphere or external identity provider credentials. Second, storage integration is achieved through the vSphere CSI (Container Storage Interface), which connects Kubernetes Persistent Volume Claims (PVCs) directly to vSphere datastores. Third, pod networking is provided by an integrated CNI (typically Antrea), ensuring secure and high-performance communication between containers. Finally, load balancing is managed through the vSphere distributed switch or NSX, allowing for the automatic creation of Layer 4 load balancers for Kubernetes services of type LoadBalancer. While VCF 9.0 supports add-on services for logging and monitoring (as mentioned in Option B), the core architectural pillars provided natively by the VKS cluster lifecycle manager are those that bridge the gap between container orchestration and the underlying vSphere infrastructure, ensuring that pods have the network, storage, and access control they require to run production workloads.

VCF 9.0 documents that you obtain access to the Supervisor (and the contexts you’re entitled to, which commonly correspond to namespaces and workload clusters) by authenticating withkubectl vsphere login. The procedure “Get and Use the Supervisor Context” explains that after you log in, a Kubernetes configuration context is generated and you can view it in$HOME/.kube/config, which is “commonly called the kubeconfig file.”

The documentation is explicit that running kubectl vsphere login --server= < KUBERNETES-CONTROL-PLANE-IP > --vsphere-username < VCENTER-SSO-USER > “creates a configuration file with the JSON Web Token (JWT) to authenticate to the Kubernetes API,” and then lists how to view and switch contexts using kubectl config get-contexts and kubectl config use-context.

This matches optionDprecisely: you don’t “download” kubeconfig from VCF Operations or a Supervisor Services page; instead, you generate/update your kubeconfig locally by logging in withkubectl’s vSphere plugin, which writes the required cluster/user/context details into .kube/config.

VCF 9.0 states that you can provision Kubernetes clusters using both GUI and CLI approaches, and it explicitly calls out the CLI clients: “the VCF CLI and kubectl provide command-line interfaces for provisioning Kubernetes clusters.” That directly maps tokubectl (A)andVCF CLI (E)as supported clients for provisioning and lifecycle operations. Separately, VCF 9.0 explains that vSphere administrators can “manage and monitor vSphere Pods, VMs, and VKS clusters by using the vSphere Client,” which corresponds tovSphere UI (C)in the question. In addition, the vSphere Client is used to access Supervisor-facing self-service interfaces (for example, the Local Consumption Interface through the vSphere Client), reinforcing vSphere UI as an operational entry point for managing Supervisor-backed services and workloads.

By contrast,Cluster APIis a controller framework (not an operator “client” for admins in this context), andesxtop/esxcliare ESXi host tools that do not represent the documented, supported interfaces for provisioning and managing VKS clusters at the Kubernetes service layer.

Kubernetes Service

When adding a Kubernetes cluster to anexisting vSphere Namespace, the workflow is initiated from within that namespace’s context in the vSphere Client. The administrator first opens the target namespace (as shown in the left navigation where the namespace is selected), then uses theKubernetes Servicearea to create and manage Kubernetes clusters associated with that namespace. In the namespaceSummaryview, theKubernetes Servicetile/card provides the entry point for cluster lifecycle actions, typically via an action link such asManage(and from thereCreate Cluster). This is because the Kubernetes cluster is anamespace-scoped resourcein the Supervisor environment: it inherits namespace-level policies and configuration such as permissions/RBAC, resource limits, storage policies, and networking selections that have already been defined for that namespace. Navigating to other areas likeStorageorNetworkis used to validate or adjust prerequisites (for example, storage policy availability or network settings), but the actual “create cluster” operation is launched fromKubernetes Servicewithin the namespace to ensure the cluster is created under the correct tenant boundary and governance model.
