The correct answer is A. 0.57 . The CSSBB material defines the process capability index as Cp = (USL − LSL) / 6σR , where σR is estimated from the control chart using σR = R̄ / d2 . For subgroup size n = 4 , the standard control chart constant is d2 = 2.059 . Using the given data:

USL = 17

LSL = 16

RÌ„ = 0.6

σR = 0.6 / 2.059 ≈ 0.291

Then:

Cp = (17 − 16) / (6 × 0.291) ≈ 1 / 1.746 ≈ 0.57

This matches option A . It is important to note that if the question had asked for Cpk , the mean of 16.4 would also matter and the value would be lower. However, the wording says “capability index” in the singular and the answer choices match Cp , not Cpk. The CSSBB text distinguishes between Cp as the capability index and Cpk as the capability ratio using the nearest specification side. Therefore, based on the CSSBB formula and the provided options, the verified answer is 0.57 .

The correct answer is B. Identifying possible problems or unusual incidents in a process . The CSSBB source states that control charts are the most powerful tools to analyze variation in most processes and that a process in statistical control is predictable because points do not exceed the control limits. The practical purpose of the chart is to highlight signals of special or assignable causes , which represent unusual conditions or potential problems requiring investigation.

Control charts are not primarily used to verify that capability is above target; capability analysis is a separate concept. They also do not maintain a relationship between control limits and specification limits, since CSSBB materials explicitly distinguish control limits from specification limits. Control charts may help estimate whether the process mean is stable, but that is not their main function. Their primary value is detecting when the process behavior changes in a meaningful way, so corrective action can be taken before more defects occur. Therefore, the best verified CSSBB answer is B , because control charts are fundamentally designed to identify possible problems or unusual process incidents.

The correct answer is C. Process control measurements . In the CSSBB material, appraisal costs are defined as the costs associated with measuring, evaluating, or auditing products or services to ensure conformance to standards and requirements. The detailed appraisal-cost checklist includes items such as inspection and test , in-process inspection , laboratory testing , equipment calibration , and test reporting , all of which are measurement- and evaluation-related activities. Process control measurements fit this category because they are used to assess current process output or performance against requirements.

By contrast, quality planning is a prevention cost, because planning is intended to prevent defects before they occur. The CSSBB prevention-cost list explicitly includes planning and design reviews . New product review and design evaluation testing are more closely aligned with early design/prevention activities than with routine appraisal of conformance. Since appraisal costs focus on checking, measuring, and verifying quality, process control measurements is the best CSSBB-based answer.

This is a two-sample t-test situation comparing the mean yields of two catalysts, with 10 observations in each sample and equal variances assumed. The degrees of freedom are n1 + n2 - 2 = 18. Because the question asks whether the yields are the same and uses α = 0.05, the appropriate test is a two-tailed t-test with critical values at ±t0.025,18, which is approximately ±2.101. The observed test statistic is t = -1.06. Since -1.06 lies between -2.101 and +2.101, the result falls inside the nonrejection region. Therefore, the null hypothesis of equal means is not rejected. In Six Sigma Analyze Phase work, this means the available data do not provide sufficient evidence that the two catalyst yields are different. That does not prove the yields are exactly identical in a practical sense, but it does mean there is no statistically significant difference detected at the 0.05 level. Since catalyst 2 is less expensive and yield appears statistically equivalent based on this test, it may be considered a viable alternative pending any additional operational considerations. Therefore, the correct answer is B.

===========

The correct answer is B. Homogeneity within subgroups: High; Chance for differences between subgroups: Maximized . The CSSBB control-chart material states that subgroups are selected in a way that makes each subgroup as homogeneous as possible and that gives the maximum opportunity for variation from one subgroup to another . This is the exact principle of rational subgrouping .

The logic is central to Shewhart charting. Within a subgroup, samples should represent conditions that are as similar as possible so that the short-term, common-cause variation is captured inside the subgroup. Across subgroups, the chart should have the best chance to reveal time-to-time or lot-to-lot changes, which is why the opportunity for differences between subgroups should be maximized. The CSSBB source further explains that when product is taken as nearly as possible at one time, this gives a minimum chance for variation within a subgroup and a maximum chance for variation from subgroup to subgroup . Therefore, the verified answer is B , which exactly matches the CSSBB definition of rational subgroup selection.

Establishing short-term measures of improvement is the best technique because it helps the team see evidence of progress before the final project goal is fully achieved. In Six Sigma team management, long projects can create discouragement when the end result is still distant, even if meaningful gains are already being made. Short-term measures provide visible milestones, reinforce momentum, and help team members recognize that their efforts are producing results. This supports motivation, confidence, and continued engagement. Asking management to inspire the team may create a temporary boost, but it does not change how progress is experienced. Redeveloping the goal may confuse the team unless the original goal is truly flawed. Shortening the deadline would likely increase frustration rather than motivation. A skilled facilitator helps the team break a large objective into manageable wins and track those improvements over time. That makes progress more tangible and builds commitment to continue. Therefore, the correct answer is A, Establish short-term measures of improvement, because it creates achievable markers that sustain team morale and focus throughout the project.

===========

Failure mode and effects analysis is the most appropriate tool because the situation involves anticipating possible failures before or during implementation and taking preventive action to reduce risk. In Six Sigma and healthcare process improvement, FMEA is used proactively to identify potential failure modes, assess their likely effects on customers or patients, estimate severity, occurrence, and detection, and prioritize actions before problems happen. The examples in this question, such as missing accounts, missing lab values, and incorrect medication order sets, are exactly the kind of implementation risks that should be evaluated through a structured pre-launch risk review. Waste analysis focuses on non-value-added activity, root cause analysis is typically used after a failure has already occurred, and Pareto analysis is used to prioritize categories of existing problems. Because management is trying to prevent harm and reduce implementation risk in advance, the correct tool is FMEA. This aligns with Black Belt expectations in Analyze and Improve work, where risk is assessed before deployment so that controls, safeguards, and contingency plans can be built into the new process.

===========

The correct answer is C. TPM . The CSSBB source states that Total Productive Maintenance (TPM) promotes coordinated group activities for greater equipment effectiveness and lists as a key feature “efforts to maximize equipment effectiveness” along with “a system of productive maintenance for a machine’s life span.”

That wording matches the question almost exactly. TPM is not just a metric or housekeeping method. It is a broad maintenance system involving operators, engineering, maintenance, and management to sustain equipment performance throughout its useful life. OEE is a measurement of equipment effectiveness, but TPM is the management and maintenance approach designed to maximize that effectiveness over the equipment life cycle. 6S is a workplace-organization and safety method, and jidoka is an autonomation concept related to stopping for abnormalities. Therefore, the verified CSSBB answer is C. TPM .

The correct answer is B. Testing products returned by customers . The CSSBB source defines external failure costs as failure costs that occur after shipment of the product, or during or after furnishing a service, to the customer . The detailed external-failure checklist includes items such as returns/rework , retesting , restocking costs , recalls/repair , warranty expenses , and customer dissatisfaction , all of which clearly happen after the product has reached the customer.

Testing products that have been returned by customers fits this category exactly, because the failure has already escaped the organization and is now being handled after delivery. In contrast, measurement system analysis is a prevention or evaluation activity, destructive testing of end-product samples is an appraisal activity, and supplier-source inspection is also appraisal-related. Therefore, the only option that clearly belongs in the external failure category is testing products returned by customers . That makes B the verified CSSBB answer.
