Juniper JN0-336 - Security, Specialist (JNCIS-SEC)

The correct answer is A. fab. In SRX Series chassis clustering, the fabric interface, shown as fab0/fab1, is the data-plane HA link used between cluster nodes. Juniper states that SRX chassis clusters use the fabric interface for session synchronization and traffic forwarding, and that the fabric link synchronizes dynamic runtime state, including session-state objects created by NAT, ALG, authentication, and IPsec processing. This is what enables stateful failover and session continuity when traffic processing moves between nodes.

Option B, fxp0, is wrong because fxp0 is the out-of-band management interface, not the chassis-cluster synchronization path. Option C, fxp1, is tempting but wrong for this question: fxp1 is the control-link interface used for control-plane cluster functions such as heartbeats and cluster control communication, not the main session-state synchronization path. Option D, swfab, is not the standard SRX chassis-cluster fabric interface name used for this function. Juniper’s clustering configuration examples specifically define fab0 and fab1 as the interfaces used for the fabric connection and data-plane RTO/session synchronization.

The correct answers are B and C. To form an SRX chassis cluster, both devices must be assigned the same cluster ID and different node IDs. Juniper states that the cluster ID identifies the cluster, while the node ID identifies the individual node within that cluster. A valid two-node SRX chassis cluster uses node 0 on one chassis and node 1 on the other chassis. Juniper’s example shows the operational-mode commands as set chassis cluster cluster-id 1 node 0 reboot on the first device and set chassis cluster cluster-id 1 node 1 reboot on the second device.

Option A is wrong because cluster-id 0 disables clustering rather than forming a cluster. It also shows configuration-mode prompt #, while this chassis cluster node assignment is performed from operational mode. Option D is doubly wrong: cluster-id 0 disables clustering, and node 2 is invalid because SRX chassis cluster node IDs are limited to 0 and 1. The exam options omit the reboot keyword, but the only logically valid pair is still SRX1 as node 0 and SRX2 as node 1 under the same nonzero cluster ID. Reference topics: HA Clustering, chassis cluster ID, node ID, operational-mode cluster enablement.

The correct answers are A and B. In SRX chassis clustering, the fab interface is the fabric data-plane link between cluster nodes. Juniper explains that data-plane software synchronizes session state using runtime objects, or RTOs, across the fabric data link, and this fabric link also supports forwarding traffic between nodes when ingress and egress processing occur on different chassis members.

swfab is also a chassis-cluster data-plane-related interface used for Layer 2 switching fabric functionality. Juniper’s Ethernet switching on chassis cluster documentation describes swfab0 and swfab1 as pseudointerfaces created for Layer 2 fabric functionality, enabling switching across the nodes. Option C, fxp1, is wrong because fxp1 is the control link interface used for cluster control-plane communication, heartbeats, and synchronization signaling, not a data-plane fabric interface. Option D, fxp0, is wrong because fxp0 is the out-of-band management interface. The clean separation is: fxp0 = management, fxp1 = control link, fab = routed/data fabric, and swfab = Layer 2 switching fabric. Reference topics: HA Clustering, fab interfaces, swfab interfaces, control link, management interface, data-plane synchronization.

The correct answers are A and B. In an SRX chassis cluster, the cluster ID identifies the chassis cluster, and valid operational cluster IDs are nonzero values. Juniper’s chassis cluster command documentation states that the system uses the chassis cluster ID and node ID to apply the correct node-specific configuration, and the command writes the chassis cluster ID and node ID to EPROM. When the cluster ID is set to 0, clustering is disabled; therefore, the HA cluster configuration is effectively ignored because the device is no longer operating as a chassis-cluster member.

Option B is also correct because Juniper states that chassis cluster ID and node ID changes take effect only after the system is rebooted. That is why the operational command format includes the reboot behavior when setting cluster-id and node. Option C is wrong because node ID 0 is valid; it identifies node0 in the two-node cluster. Option D is wrong because SRX chassis clusters use node IDs 0 and 1 only; the 1–255 range applies to cluster IDs, not node IDs. Reference topics: HA Clustering, cluster ID, node ID, EPROM, chassis cluster enablement, node-specific configuration.

The correct answers are B and C. The exhibit shows the command request security idp security-package install failing with: “Security package installation disabled temporarily due to invalid license.” In the IDP update workflow, the SRX must have a valid IDP/AppSecure-related license to install updated security packages. Juniper’s support guidance for an expired IDP license states that if the IDP license expires, attacks continue to be inspected, but IDP update installation is not allowed. That maps directly to this exhibit: the existing IDP engine and currently installed attack database can continue to inspect traffic, but the device cannot install the newer downloaded package until licensing is corrected.

Option A is wrong because expiration does not immediately stop all IDP inspection; it prevents installing new updates. Option D is not the best answer because the specific operational behavior shown is consistent with an invalid/expired license condition after attempting a package install, not proof that no license was ever installed. The practical remediation is to validate the installed license, renew or reinstall the correct IDP license, then retry the security-package installation. Reference topics: IDP licensing, security-package download/install, attack database updates, installed signature inspection behavior.

The correct answers are C and D. Static attack object groups are manually defined groups. Juniper states that custom attack groups are static in nature because the attacks are explicitly specified in the group; therefore, those attack groups do not change when the security database is updated. This is the key difference between static groups and dynamic groups. Dynamic groups use matching criteria and can automatically update membership when the signature database changes, but static groups do not behave that way.

Option C is correct because updating the IPS/IDP signature database does not automatically add or remove members from a static attack group. Option D is correct because the administrator must explicitly add the desired attack objects to the custom static group. Option A describes dynamic matching behavior, not static group behavior. Option B is also dynamic-group behavior; Juniper Security Director documentation says dynamic group membership is automatically updated during signature updates based on the group’s matching criteria. Static groups are intentionally deterministic: they include only the attacks manually selected by the administrator. Reference topics: IDP attack objects, static attack groups, custom attack groups, dynamic attack groups, IPS signature database updates.

The correct answers are A and D. In IKEv1-based IPsec VPNs, there are two distinct negotiation phases. IKEv1 Phase 1 establishes the secure and authenticated IKE channel between peers. That means the IKE SA is built during Phase 1. Juniper describes Phase 1 as the negotiation of proposals for how to authenticate and secure the channel, including encryption algorithms, authentication algorithms, Diffie-Hellman group, and authentication method.

IKEv1 Phase 2 then uses that secure channel to negotiate the IPsec SAs that protect actual user traffic through the VPN. Juniper states that Phase 2 negotiates security associations to secure the data traversing the IPsec tunnel, and that the Phase 2 proposal includes the security protocol, such as ESP or AH, plus the selected encryption and authentication algorithms. Option B is wrong because IKEv1 SAs are not established in Phase 2; Phase 2 creates IPsec SAs. Option C is wrong because Phase 1 does not create the data-plane IPsec SA; it creates the secure IKE control channel used for Phase 2 negotiation. Reference topics: IPsec VPN, IKEv1 Phase 1, IKE SA, IKEv1 Phase 2, IPsec SA, ESP/AH proposals.

The correct answer is A. It supports a maximum of two domains. Juniper’s Active Directory identity-source configuration guidance states that an SRX Series Firewall using the integrated user firewall/Active Directory identity source can be configured for a maximum of two domains. That is the exact limit relevant to this question. The same Juniper configuration page separately states that a maximum of 10 domain controllers can be configured, which directly eliminates option C because the supported figure is not 20 Active Directory servers per domain.

Option B is wrong because Active Directory identity source is not presented as a logical-systems feature in the JNCIS-SEC identity-aware firewall context. Option D is wrong because the primary Active Directory mechanism reads Windows domain controller event logs and uses WMI/DCOM plus LDAP to build IP-to-user and group mappings. Juniper describes the SRX as reading and monitoring the Windows event log on the domain controller, then using LDAP to obtain user/group information. Non-domain or non-Windows cases typically require alternate authentication behavior such as captive portal, not native Active Directory event-log tracking.

Reference topics: Identity-Aware Security Policies, Active Directory identity source, integrated user firewall, domain limits, domain controllers, WMIC, LDAP mapping.

The correct answers are C and D. The cSRX is Juniper’s containerized SRX firewall, intended for lightweight virtual and container environments where rapid deployment and high density matter. Juniper’s cSRX documentation lists supported security capabilities including basic firewall policy, NAT, Intrusion Detection and Prevention, content security/UTM functions, ATP Cloud, SSL Proxy, AppID, AppFW, and AppTrack. That supports option C, because cSRX provides SRX security services in a containerized footprint rather than requiring a full VM-based firewall appliance.

Option D is also correct because Juniper identifies the cSRX’s small footprint and minimum resource reservation requirements as key benefits; it is designed to scale more densely than VM-based firewall options. Juniper’s Day One cSRX guide specifically identifies faster deployment, a small footprint, and reduced resource consumption as major benefits. Option A is not the best answer for this exam item because the question asks for cSRX deployment benefits, not merely forwarding-mode support. Option B is wrong because the tested cSRX advantage is not a default three-zone configuration. Reference topics: cSRX container firewall, virtual SRX deployment, firewall/NAT/IPS/UTM services, lightweight resource footprint.
