Paloalto Networks PCNSE - Palo Alto Networks Certified Security Engineer (PCNSE) PAN-OS 11.0

Based on PAN-OS 11.0 documentation, the forwarding configuration for specific log types in Device > Log Settings involves selecting log types for system-level logs, which include HIP Match and Configuration logs.

Explanation for Each Option

A. Threat

Threat logs record detected security threats such as malware, viruses, and vulnerabilities.

Forwarding of Threat logs is not configured in Device > Log Settings. Instead, Threat logs are forwarded using Log Forwarding Profiles applied to Security Policies.

Verdict: Incorrect.

B. HIP Match

HIP Match logs capture information about endpoint compliance reported by GlobalProtect clients.

These logs can be configured for forwarding in Device > Log Settings for monitoring and compliance purposes.

Verdict: Correct.

C. Traffic

Traffic logs provide details about allowed or denied network traffic.

Forwarding of Traffic logs is configured using Log Forwarding Profiles applied to Security Policies, not in Device > Log Settings.

Verdict: Incorrect.

D. Configuration

Configuration logs track administrative changes to the firewall, such as updates to policies, settings, and objects.

These logs can be forwarded from Device > Log Settings for auditing purposes.

Verdict: Correct.

Correct Answer

B. HIP Match

D. Configuration

Key Points from PAN-OS 11.0 Documentation

Device > Log Settings is specifically for system-related logs like HIP Match and Configuration.

Logs like Threat and Traffic are handled through Log Forwarding Profiles applied to Security or NAT policies.

Documentation Reference

For further details, refer to the official Palo Alto Networks PAN-OS 11.0 Admin Guide under Device > Log Settings. This section outlines which log types can be forwarded from this menu.

In Palo Alto Networks firewalls, the processing of NAT rules occurs in a top-down fashion, similar to security policies. To exclude a specific IP address from a broader source NAT rule, a more specific NAT rule must be placed above the broader rule.

C. Place a more specific NAT rule above the broader one:

Create a source NAT rule (NAT-Rule-1) to translate the broader network range (10.0.0.0/23) with dynamic IP and port translation. This rule allows the majority of the subnet to access the internet through NAT.

Create another NAT rule (NAT-Rule-2) with the source IP address in the original packet set specifically to the IP address that should not be translated (10.0.0.10/32). In this rule, set the source translation to none, indicating that this traffic should not be translated and thus not allowed to access the internet.

Place NAT-Rule-2 above NAT-Rule-1 in the NAT policy list. This ensures that the more specific rule (NAT-Rule-2) is evaluated first. If traffic matches NAT-Rule-2, it will not be translated or allowed to the internet, effectively excluding the specific server from internet access.

This configuration leverages the principle of specificity and the order of operation in NAT policies to exclude a specific IP address from source NAT translation, thereby preventing it from accessing the internet.
